Galvanized Iron Cutting Leveling Roll Forming Machine Sheet Metal Slitting Machine

Machine introduction

Application areas:

1. Metal products industry:

-In steel processing enterprises, it is used for straightening and leveling steel plates, galvanized plates, stainless steel plates, etc.

-In aluminum processing, it is used to ensure the flatness of aluminum strips.

2. Packaging industry:

-For enterprises that require the use of metal foil or thin sheets as raw materials in the production of cardboard boxes, plastic boxes, etc., the strip leveling function ensures the smoothness of the material surface, which is beneficial for subsequent printing and molding processes.

3. Home appliance manufacturing industry:

-Household appliances such as refrigerators and washing machines are usually made of metal sheets for their shells. A strip leveling machine can help these sheets achieve the required flatness to ensure that the finished product has a beautiful appearance and stable structure.

4. Automotive manufacturing industry:

-The car body, components, etc. require a large amount of metal sheets, and the strip leveling machine can ensure the flatness of these sheets before stamping, thereby ensuring the consistency and quality of the parts.

5. Construction industry:

-In the construction industry, for building materials such as color steel plates and steel tiles, strip leveling can ensure the flatness of the materials and facilitate installation and use.

Product introduction

Galvanized Iron Cutting Leveling Roll Forming Machine Sheet Metal Slitting Machine

Suppliers of various types of support plates

1. Loading:

-The coil is loaded onto the loading rack of the machine.

2. Open book:

-Unfold the coil into a continuous strip using an unwinding mechanism, such as a hydraulic or electric unwinding machine.

3. Guiding positioning:

-The use of guiding devices ensures that the material advances along the correct path, typically including guide rollers and lateral adjustment devices to control the position of the material.

4. Pre straightening:

-Before entering the main straightening section, a pre straightening process may be required to initially eliminate bending in the coil.

5. Straightening:

-This is the most crucial part of the entire process. The material passes through a series of straightening roller groups, which apply force to the material according to the set pressure to eliminate defects such as wave shapes and distortions in the material.

-The number and spacing of straightening rollers can be adjusted according to the thickness and hardness of different materials.

6. Flatness:

-After straightening, the material may have some slight deformation, so it is necessary to further improve the surface quality through a leveling mechanism.

-Flattening can be achieved through the pressure between multiple rollers, making the material surface smoother and smoother.

7. Cutting/Slitting:

-If it is necessary to divide the material into strips of a specified width, it can be done through cutting or slitting mechanisms.

-Slitting machines are usually equipped with precision cutting tool systems to ensure cutting accuracy.

8. Roll up:

-The processed material is rolled back onto a new reel, ready for subsequent processing or packaging.

9. Quality inspection:

-Throughout the entire process, visual inspection systems or other quality control devices may also be equipped to monitor the quality and performance of the product.

10. Unloading:

-The final step is to unload the finished product from the machine and perform necessary packaging and storage.

Technical parameter

Number of leveling rollers	6 on top and 7 on bottom, a total of 13 spindles
Leveling axis diameter	100mm
middle plate thickness	30mm (customizable)
Host power	3kw
hydraulic station power	3kw (customizable)
Transmission method	Wall mounted gear transmission
Cutting method	Fully automatic CNC counting, with frequency conversion, accurate counting

The company has vigorously introduced the German professional roller design software COPRA, which can design various rollers according to customer needs.

Manual uncoiler

Free manual uncoiler

The coil inner diameter: φ450-550mm;
Max. outer coil diameter: φ1000mm-1250mm
The max capacity: 5T

Machine shaft

All machines are finished with Cr12 rollers
Shaft hardness 58-60
Hardening depth 0.8mm
Surface roughness ra0.1m-0.35m
High quality shaft with a service life of over 15 years

Customer usage site

We designed and produced this machine for the customer based on the product drawings provided by him.
